  • Hitachi TCM-X300 Pick and Place Machine
Hitachi TCM-X300 Pick and Place Machine

Hitachi TCM-X300 Pick and Place Machine

  • Hitachi TCM-X300 Pick and Place Machine
  • Head: 12 Heads
  • PCB:560 mm * 460 mm
  • Equipment weight: 4800KG
  • Product description: Hitachi TCM-X300 Pick and Place Machine -Good Price! Good Quality! Good Service!
  • INQUIRY

Hitachi TCM-X300 pick and place machine

Products Description:


Head: 12 Heads
Sewing speed (Best condition): 0.075 second
PCB dimensions: max. 560 mm * 460 mm, 50 mm * 50 mm
: 0201 - 32/32 mm QFP SOP, altitude 6 mm or less 0
Charge quantity: 144

Trend: Left Right (Right Left: Option)
Air: 4.5 - 6.9 Kgf / cm 2

Power source and power source: 200 V - 220 V 3 PH, 50/60 Hz, 16 KVA, ✧ Source: 100 L / min
Equipment dimensions: L 6000 mm, W 2247 mm, H 1695 mm
Equipment weight: 4800 kg
Maker: Hitachi (Sanyo)


Target board dimensions (mm) 50 × 50 to 330 × 250 t = 0.5 to 5.0 (TCM-X 110 J)
50 × 50 to 330 × 250 t = 0.5 to 5.0 (TCM-X 110 M)
50 × 50 to 560 × 460 t = 0.5 to 5.0 (TCM-X 300 S)
(The board carrying range is 610 x 460 mm.)
Target packaging 8 mm (paper tape) 8 - 44 mm (embossed tape), bulk
Number of mounted feeders (8 mm tape) (book) 60 (30 × 2) (TCM - X 110 J)
120 (30 × 4) (TCM-X 110 M)

72 (36 × 2) (TCM-X 300 S)


Power source used 3 phase AC 200 V ± 20 V 50/60 Hz Approx 14 kVA
Air pressure used (MPa) Dry clean air 0.45 to 0.69
Maximum wearing time (sec / piece) (optimum condition) 0.075
(Option 0.072)
Equipment dimensions (mm) Width x Length x Height
(Tower lamp height) 2,400 × 1,953 × 1,695 (2, 100) (TCM-X 110 J)
4,500 × 1,953 × 1,695 (2, 100) (TCM-X 110 M)
3, 130 × 2, 223 × 1, 695 (2, 100) (TCM-X 300 S)
Mass (kg) Approximately 3,400 (TCM - X 110 J) / approximately 3,950 (TCM - X 110 M)
About 4,000 (TCM-X 300 S)

Option Installed Coordinate Teaching Parts Library Teaching Barcode

Reel Check Barcode Model Switching BGA,

CSP Black Light Board Recognition Special Lighting



Keywords:

China reflow oven, Pick and place machine factory,China chip mounter, SMT chip mounter Manufacturer, Lead Free Reflow Oven factory, wave soldering machine manufacturer,pick and place machine supplier.

Flason Electronic Co.,ltd provide a full smt assembly line solutions, including Lead free reflow oven, wave soldering machine, SMT pick and place machine, smt stencil printer, PCB conveyor manufacturer, PCB unloader, chip mounter, SMT AOI machine, SMT SPI machine, SMT X-Ray machine, SMT assembly line equipment, PCB production Equipment smt spare parts etc any kind SMT machines you may need, please contact us for more information: wechat whatsapp:008613691605420, Skype: flasonsmt, Email: sales@flason-smt.com
